Pyroguard Marine

Fire duration 30-60 mins

Product type Toughened

Thickness 6-32mm

Weight 15 – 53kg/m2

Acoustic dB Up to 42dB

Impact protection 1B1, 1C1

Light transmission 82-90%

U-value 3.6 – 5.7kw/m2

Temp Range +100 and -10/+45℃

Marine environments are amongst some of the most beautiful yet challenging on our planet…

The ever changing extremes in weather conditions and temperatures combined with noise reduction, impact and load bearing requirements demand for robust, high performance products to successfully cope with the pressures of such a setting.

Whether you’re looking for a solution for commercial vessels or luxury leisure cruisers, our toughened range of fire safety glass products can all be ‘Wheelmark’ certified and are well equipped to perform to the highest possible requirements.

About Pyroguard Marine

Classification: A-B

Fire Resistance: 30-60 mins

A range of toughened and gel-filled fire safety glass providing integrity only and integrity and insulation protection against the passage of flames, smoke and toxic gases from 30 to 60 minutes. The solutions provide 1B1 or 1C1 impact classification, high-performance acoustic properties and UV stability.

Select an option below:

Application

Certification

Features

Benefits

Available in options ranging from 6 mm to 32 mm thicknesses
Suitable for both internal and external applications
Suitable for use with steel and aluminium profiles
Specifically developed for the demands of marine and offshore applications including; passenger ships, yachts, specialist vessels and container ships

A and B Classification
30 – 60 mins

Toughened fire-rated safety glass
Maximum manufactured size: 2400 mm x 4000 mm
High performance – impact tested and certified to EN12600:2002
Bespoke solutions, including butt-joint applications
A + B classification providing protection from fire, heat and smoke
Exceptional visual quality
Fully UV stable
Large certified pane dimensions

Versatile and flexible to your design requirements
Provides optimum (Class A2) level of reaction to fire
Multi-functional compositions give you flexible solutions
Noise reduction qualities
Robust and suitable for the demands in marine environments

Solutions suitable for:

Passenger ships

Yachts

fire safety glass at sea - pyroguard marine

Offshore platforms

Carrier and container ships

Need some technical information?

You can download our data sheets here:

PYROGUARD T- 13-1, 15-1, 19-1

PYROGUARD T-A30 B30 18-2

PYROGUARD T-A60 25-3

PYROGUARD T-A60 32-2 SWS
